Perfect compatibility with ATX, Micro-ATX, Mini-ITX industrial motherboards
High quality 1.2mm SGCC environmentally friendly steel, high temperature spraying wear-resistant paint, durable corrosion resistance, paint anti-fingerprint
Compatible with 2 x 3.5 "hard drive bays 2 x 5.25" optical drive bays
Standard 1 12025 fan, good cooling effect, quiet and durable
Provides 7 full-height PCI/PCIE expansion slots with battens and retention brackets
Optional COM port and MIO ready port for knock-out hole
The power switch, reset switch, power indicator and hard disk indicator are arranged in the front door which can be locked and seen through, effectively preventing unauthorized operation
Compatible with 250W, 300W, 400W AC and DC industrial power supplies
It can be widely used in industrial fields with more dust, more oil and more vibration
Conform to GB/T 9813.4-2017
规格 下载产品文件
Product Code | IPC-4U610 |
Product Type | 4U rack type intelligent manufacturing machine |
Compatible Motherboard Types | Compatible with ATX, Micro-ATX, Mini-ITX industrial motherboards, full and half length cards |
2.5"drive ready bit | 1 x 2.5 "SSD ready mounting position |
3.5"drive ready bit | 2 x 3.5 "hard drive mounting bays with shock absorption (optional 6 x 3.5" hard drive mounting bays) |
5.25"drive ready bit | Two 5.25 "CD-ROM mounting positions with shock absorption, covered by blank bezel when installed |
Front I/O port | 2 USB ports, power switch, reset switch, power indicator, hard disk indicator, door with lock |
Rear I/O port | Reserve 10 DB9 serial ports and 2 DB25 parallel ports or MIO ports |
Expansion slot | Provides 7 full-height PCI/PCIE expansion slots with battens and retention brackets |
cooling system | 1 x 12025 fan with removable dust screen as standard |
Atmospheric conditions of working environment | Temperature 0℃~45℃, relative humidity 20%~80%, atmospheric pressure 85~105kPa |
Storage Ambient Atmospheric Conditions | Temperature -40℃~55℃; relative humidity 20%~93%(40℃), atmospheric pressure 85~105kPa |
anti-vibration performance | Operating state 1Grms@5~500Hz , non-operating state:2Grms@5~500Hz |
impact resistance | 3-way, 10G (11ms half sine wave) , 3 times/way |
Reference standard of complete machine | Comply with GB/T 9813.4-2017(National Standard for Industrial Application of WeChat Computer) |
Power | AC input 220V,50Hz(220~242V,50~51Hz) Standard 300W ATX power supply, compatible with 250W, 300W, 750W ATX power supplies |
size (W*H*D) | 430mm *178mm *450mm |
Weight | Chassis with power supply approx. 15KG |
Complete machine:
Ordering Information:
Product Code | Power | 2.5"bit | 3.5"bit | 5.25"bit | USB2 | COM | Slot | Switch |
IPC-4U610-A | 300W | 1 | 2 | 2 | 9 | 6 | 7 | ATX |
IPC-4U610-B | 300W | 1 | 2 | 2 | 11 | 6 | 7 | ATX |
IPC-4U610-D | 750W | 1 | 2 | 2 | 9 | 6 | 7 | ATX |
Accessories List:
Accessory Description | Specification | Number |
cable tie | Cable Tie White Length 150mm LEAD-FREE | 2 |
AC Power Cord | AC = 3 P 10A 250 V 60227 IEC 53 3 * 0.75mm2 L = 1500 AC 220 V | 1 |
